Precision Shop Drawings & Detailing Services
Bridging design intent and real-world construction. We produce sub-millimeter accurate, fabrication-ready shop drawings and erection plans for steel fabricators, millwork craftsmen, precast plants, and MEP subcontractors across the USA.
What Are Shop Drawings and Why Are They Mission-Critical?
Architectural and engineering contract drawings describe design intent, aesthetics, and general spatial dimensions—they are not blueprints for manufacturing. Shop drawings are the critical bridge that translates design concepts into exact manufacturing instructions, field tolerances, and erection procedures.
Zero Field Clashes
Every dimension, fastener, connection clip, and clearance is cross-verified against architectural, structural, and MEP models before fabrication begins.
Precise Material Takeoff
Itemized bills of materials (BOM), hardware counts, linear footages, and piece weights eliminate material waste and purchasing overruns.
Fast Submittal Approval
Clean annotations, cross-referenced project specs, and professional title blocks ensure rapid sign-off by architects and structural EORs.
Shop Drawing Categories We Deliver
Each discipline has unique fabrication standards, weld specifications, and field clearances. Explore our 5 specialized categories below and request a customized quote for your trade.
Steel Shop Drawings
Complete structural and miscellaneous steel detailing produced in Tekla Structures. Built for fabricators needing flawless CNC files (.NC1), piece marks, and field erection blueprints.
- AISC & NISD compliant connection design
- Anchor bolt layouts & foundation embed plans
- Single-part and multi-assembly shop sheets
- Comprehensive bills of materials (BOM) & bolt lists
- Miscellaneous steel: stairs, railings, ladders & canopies
Millwork / Casework Shop Drawings
High-end architectural woodwork, custom cabinetry, reception desks, and acoustic paneling. Formatted for commercial millwork shops and custom interior fabricators.
- Architectural Woodwork Institute (AWI) standard compliance
- Detailed elevations, plan views, and sectional cuts (1:1 / 1:2)
- Joinery details, veneer matching & grain directions
- Hardware schedules, drawer slides, hinges & pulls
- Integrated lighting channels, wire grommets & reveals
Precast Concrete Shop Drawings
Architectural and structural precast panel drawings for parking garages, commercial facades, sound walls, and stadium risers. Designed to Precast/Prestressed Concrete Institute standards.
- PCI Design Handbook standards alignment
- Individual panel geometry, formwork dimensions & finishes
- Rebar reinforcement layouts & prestressed strand schedules
- Lifting insert, crane rigging, and handling calculations
- Field erection diagrams and connection hardware details
MEP Shop Drawings
Contractor-coordinated installation and spool drawings for mechanical ductwork, electrical conduit racks, process piping, and plumbing risers with zero spatial clashes.
- Pre-fabrication spool sheets with cut lengths & weld tags
- Hanger, seismic strut, and trapeze point coordinates
- Equipment pad dimensions & rough-in clearance verification
- Coordination with architectural ceiling grids & steel beams
- Total Station point files (.CSV / .TXT) for field robotic layout
Architectural Shop Drawings
High-performance building envelope details including glass curtain walls, storefront framing, metal composite panel (ACM) rainscreens, louvers, and architectural roofing.
- Glazing schedules, mullion profiles & glass thickness specs
- Flashing, waterproofing membrane, and vapor barrier transitions
- Thermal expansion joints, weep holes & deflection clips
- Anchor brackets, clip angles & structural substrate embeds
- Wind load and structural engineer review submittals
Our 5-Step Detailing Process
A battle-tested production pipeline ensuring complete accuracy, fast submittal approvals, and smooth fabrication handover.
Submit Drawings
Upload your design drawings, specifications, project addenda, and manufacturer cut sheets.
Review & Takeoff
Our detailing directors review the scope, verify dimensional tolerances, and generate RFIs for any discrepancies.
Drafting & Detailing
Our senior drafters model the components in Revit, AutoCAD, or Tekla, developing exact assembly sheets.
Multi-Tier QA Check
A senior quality assurance manager audits all dimensions, weld symbols, and title blocks against contract specs.
Final Delivery
Receive print-ready submittal PDFs, native CAD/BIM files, and CNC data. Includes 2 complete rounds of revisions.
Sample Shop Drawing Deliverables
Examine our high-resolution drafting details, connection geometry, and title block presentation. Click any drawing to view in high definition.
Structural Steel Connection Package
Tekla Structures model outputs showing wide-flange moment connections, stiffener plates, bolt holes, and shop weld callouts.
Custom Reception Millwork Assembly
Detailed fabrication package for curved walnut veneer reception desk, solid surface countertops, and hidden LED channel joinery.
Central Plant Chilled Water Spooling
Prefabrication pipe spool sheets with exact cut lengths, flange weld tags, and robotic layout point coordinates for mechanical contractor.
Unitized Curtain Wall System
Aluminum storefront framing details, thermal break extrusions, weep drainage channels, and structural anchor connections.
Insulated Precast Wall Panels
Piece drawings for architectural precast panels showing reinforcement cages, lifting clutch embeds, and reveal patterns.
Commercial Building Envelope CD Set
AIA-compliant construction document set including roof parapet flashings, window head/sill assemblies, and wall sections.
